Brand Name : D&T
Model Number : DTC-E1212
Certification : ce
Place of Origin : CN
MOQ : 1set
Price : USD20000~40000/SET
Payment Terms : T/T, L/C, Paypal, D/A, Western Union, MoneyGram
Supply Ability : 20 sets per month
Delivery Time : 20days
Packaging Details : packed with pvc film into 20 container
Item : CNC 2D EPS cutting machine
Type : DTC-E1212
Product Size : 2000*1300*1000mm
Cutting Line Diameter : 0.5-1.2mm
Control System : Industrial Computer
Cutting Speed : 0-1.5m/min(adjusted)
Precision : ±1mm
Power : 13.5kw,380v,50hz
Weight : 1200kgs
Color : as cliebts requirement
Name : eps cutting machine
Warranty : 1 year
Automatic EPS Hot Wire CNC Foam Cutter 380V , Block Cutting Machine
styrofoam cutting machine/ eps block cutter/ electric hot wire eps cutter
1. Main Introduction:
1 The cutting process can be showed on the display screen;
cutting speed is adjustable (max. 4000mm/min).
2. With function of cutting stroke protection:
when exceeds the regulated cutting stroke,
the machine can stop running automatically
3. With functions of parameters memory while fail of electricity;
reverse cutting and rotating, mirror symmetry;
clearance compensation, etc.
Note: The cutting machine in special specifications can be customized
according customers requirement.
2. Description Of 2D EPS cutting machine
Suit for: Polystyrene
Cutting line: Hot Wire
D&T series 2D EPS cutting machine is a special cutting machine,
which is for complex shapes of EPS products.
THis kind of cutter has one or sevaral cutting lines for different production request.
All the machines are driven by the remarkable D&T Profiler software,
which speeds up the design process and enables the operator to
obtain the best yield from the foam block.
Hot Wire Contour Cutter has perfect safe system to provide the accident.
It include: All Motor will stop when the safety door be opened;
Exigency button on both machine and control box for accident;
brake system when cutting line broken.
3. Technical DaTa of 2D EPS cutting machine
TECHNICAL DATA | |||
Type | DTC-C2012 | DTC-E3012 | DTC-E6012 |
Max. Product Size | 2000*1300*1000mm | 3000*1300*1300(mm) | 6000*1300*1300(mm) |
Cutting Line | 0.5~1.2mm | ||
Control System | Industrial Computer | ||
Software | D&T Profiler | D&T Profiler | D&T Profiler |
Cutting Speed | 0~1.5m/min | 0~1.5m/min | 0~1.5m/min |
Presicion | ±1mm | ||
Power | 13.5kw, 380v, 50hz | 14.5kw, 380v, 50hz | 14.5kw, 380v, 50hz |
Overall Weight | 1200kg | 1500kg | 2000kg |
![]() |
